Petrochemical Cryogenic Air Separation Equipment High Purity Liquid Oxygen Nitrogen Equipment

  • Petrochemical Cryogenic Air Separation Equipment High Purity Liquid Oxygen Nitrogen Equipment
  • Petrochemical Cryogenic Air Separation Equipment High Purity Liquid Oxygen Nitrogen Equipment
  • Petrochemical Cryogenic Air Separation Equipment High Purity Liquid Oxygen Nitrogen Equipment
Place of Origin China, Henan
Brand Name JF
Certification ISO,CE,ASME,BV,PED,GHOST
Minimum Order Quantity 1
Price negotiable
Delivery Time 18 months after delivery
Payment Terms L/C, D/A, D/P, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Cryogenic Air Separation Plant Core Components PLC, Pressure Vessel, Gear, Motor, Engine, Bearing, Gearbox, Pump
Dimension(L*W*H) 18300mm*2450mm*13500mm Warranty 18 Months After Delivery
Voltage 440V/380V/50-60hz Key Selling Points High Safety Level
Advantage Stable Output Performance
High Light

Petrochemical Cryogenic Air Separation Equipment

,

Cryogenic Air Separation Equipment 380V

,

Cryogenic Air Separation Equipment High Purity
Leave a Message
Product Description

Raw material air is put through a filter to remove dust and mechanical matter, inhaled by air filter from the atmosphere to remove dust and other mechanical impurities. Air is compressed to 1.0 MPa(G) by air compressor, and it goes to purifier after its condensed water is separated in water separator via pre-cooler. There are two adsorbers that work alternatively, i.e. one vessel is adsorbing the impurities while the other regenerates and blows off.



Then the clean high-pressure air is divided into two streams after it enters main heat exchanger (upper) to exchange heat with oxygen, nitrogen and waste gas from main heat exchanger (lower).





(LO2) Liquid oxygen capacity 30NM3/H - 40000NM3/H
(LO2) Liquid oxygen purity range ≥99.6%
(LN2) Liquid nitrogen capacity: 30NM3/H - 40000NM3/H
(LN2) Liquid nitrogen purity range: ≥99.99%
(LAr) Liquid argon capacity: 30NM3/H - 1350NM3/H
(LAr) Liquid argon purity range ≤2PPmO2, ≤3PPmN2
Medium Operating Pressure 0.1MPa - 8.5MPa





Petrochemical Cryogenic Air Separation Equipment High Purity Liquid Oxygen Nitrogen Equipment 0
